The core characteristics of the stainless steel cable tray bracket are its excellent corrosion resistance and structural adaptability.Made from 304 or 316 stainless steel,it effectively resists moisture,acid-base atmospheres,and chloride ions.Its cantilever design allows for easy adjustment of height and horizontal position, adapting to various sizes of ladder-type or trough-type cable trays.The installation method is flexible,as it can be fixed to walls,floors,or ceilings via a base plate to form a complete cable support system.The overall design lacks sharp edges,protecting cable jackets from damage during installation and maintenance.
The primary material is austenitic stainless steel 304 or 316/L.The arm length can be customized as needed,commonly 300mm,450mm,600mm.The width and thickness of the support arm are optimized for different tray spans,typically 3-5mm thick.The mounting holes are spaced at standard intervals,such as a 50mm module,for precise installation.The surface is usually stainless steel's natural color(2B finish)or brushed,maintaining aesthetics and cleanliness.Products must comply with international standards for cable management systems like NEMA VE1 or IEC 61537.
Primarily used in data center server rooms to neatly and orderly support the vast quantities of network and power cables above server racks.In industrial plants,they are used to route power and control cables,keeping workshops tidy and ensuring safety.In the food,beverage,and pharmaceutical industries,they are the preferred choice due to their easy cleaning and resistance to sanitizing chemicals.They are also suitable for electrical wiring systems in large public facilities like subways and airports.
